Endorfy Supremo FM5 Gold 1000W (EY7A010)

Type: Active PFC (Power Factor Correction) Power Output: 1,000W, 1,050W Efficiency Rating: 80 Plus Gold (indicating high efficiency, typically above 90% under typical loads) Cable Type: Fully Modular (allows for easier cable management and better airflow) Protection Systems: OVP (Over Voltage Protection) UVP (Under Voltage Protection) OCP (Over Current Protection) SCP (Short-Circuit Protection) OPP (Over Power Protection) OTP (Over Temperature Protection) SIP (Surge-Inrush Protection) Voltage Rails: +12V Rail: 83A (Amps), Maximum combined power: 996W +5V Rail: 20A +3.3V Rail: 20A Maximum Combined Power for 5V & 3.3V Rails: 100W Modular Connectors: ATX 24-pin: 1x 24-pin connector for motherboard ATX 8-pin (EPS 12V): 2x 4+4 pin connectors for CPU power PCI Express 8-pin: 4x 6+2 pin connectors for graphics cards SATA: 8 connectors for powering SATA devices (e.g., SSDs, HDDs) Molex 4-pin: 1 connector for older peripherals Cooling: Cooling Type: Active (using a fan for cooling) Number of Fans: 1 Fan Size: 120mm x 120mm (standard size for efficient cooling) Physical Characteristics: Form Factor: ATX Dimensions: 150mm (W) x 140mm (L) x 87mm (H)
